ES Components | A Franchised Distributor and Manufacturer




Microchip Logo

ES Components is an authorized distributor for all of Microchip's products.  Our focus is Microchip's bare die and high-reliability packages.


Featured Microchip Product:  Flash Memory

Parallel NOR Flash Memory (High Performance, Low Power):

Density VCC Part Number Interface Temperature Range Data Sheet
2Mb 3V SST39VF020-90-4C-ESC 512kx8 0°C to +70°C link
2Mb 3V SST39VF200A-90-4C-ESC 128kx16 0°C to +70°C link
4Mb 1.8V SST39WF400B-70-4C-ESC 256kx16 0°C to +70°C link
4Mb 1.8V SST39WF400B-70-4I-ESC 256kx16 -40°C to +85°C link
4Mb 3V SST39VF400A-70-4C-ESC 256kx16 0°C to +70°C link
4Mb 3V SST39VF400A-70-4I-ESC 256kx16 -40°C to +85°C link
4Mb 3V SST39VF040-90-4C-ESC 512kx8 0°C to +70°C link
8Mb 1.8V SST39WF800B-70-4C-ESC 512kx16 0°C to +70°C link
8Mb 1.8V SST39WF800B-70-4I-ESC 512kx16 -40°C to +85°C link
8Mb 3V SST39VF801C-70-4C-ESC 512kx16 0°C to +70°C link
8Mb 3V SST39VF800A-70-4I-ESC 512kx16 -40°C to +85°C link
16Mb 1.8V SST39WF1601-70-4C-ESC 1Mx16 0°C to +70°C link
16Mb 1.8V SST39WF1601-70-4I-ESC 1Mx16 -40°C to +85°C link
16Mb 1.8V SST39WF1601-70-4I-ESC 1Mx16 -40°C to +85°C link
16Mb 3V SST39VF1601-90-4C-ESC 1Mx16 0°C to +70°C link
16Mb 1.8V SST39WF1602-70-4C-ESC 1Mx16 0°C to +70°C link
16Mb 1.8V SST39WF1602-70-4I-ESC 1Mx16 -40°C to +85°C link
16Mb 3V SST39VF1602-90-4C-ESC 1Mx16 0°C to +70°C link
32Mb 3V SST39VF3201-90-4C-ESC 2Mx16 0°C to +70°C link

Serial Flash Memory (Small Footprint Serial Peripheral Interface Flash Memory):

Density VCC Part Number Temperature Range Datasheet
1Mb 3V SST25VF010A-33-4I-ESC -40°C to +85°C link
4Mb 3V SST25VF040B-40-4I-ESC -40°C to +85°C link
4Mb 1.8V SST25WF040B-40I-ESC -40°C to +85°C link
8Mb 3V SST25VF080B-25-4C-ESC -40°C to +85°C link
16Mb 3V SST26VF016B-104I-ESC -40°C to +85°C link
64Mb 3V SST26VF064B-104I-ESC -40°C to +85°C link

Microchip 8-bit PIC Microcontrollers (MCU) Enabled for Bare Die Sales


MICROCHIP - MICREL:  LDO Regulators, MOSFET Drivers, ECL Logic

Microchip Micrel Logo

Microchip Technology Incorporated is a leading provider of microcontroller, mixed-signal, analog and Flash-IP solutions.  On August 3, 2015, Microchip completed their acquisition of Micrel, Incorporated.

Microchip now offers products from the former Micrel such as high-performance analog and high-speed mixed signal, LAN and timing and communications solutions markets.

These products include high performance analog, power, advanced mixed-signal and radio frequency semiconductors; high speed communication, clock management, and LAN solutions including Ethernet switch and physical layer transceiver integrated circuits. These products address a wide range of rapidly growing end markets including cellular handsets, portable and enterprise computing, enterprise and home networking, wide area and metropolitan area networks and industrial equipment.

ES Components offers many of these devices in bare die or wafer form including many Low Dropout Voltage Regulators, MOSFET Drivers and ECL Logic Devices as well as the products from the former Phaselink.
